Ajax Hub (2G) Jeweller

Sale price 314,98 EUR
Color: Melna
Installation: Yes

Hub (2G) Jeweller is the central unit of the Ajax security system, featuring dual communication channels (Ethernet and SIM 2G), a wireless range of up to 2000 m, and support for up to 100 devices. Running on the OS Malevich real-time operating system, it ensures sabotage protection, encrypted two-way communication, and easy control via Ajax mobile and desktop apps. The built-in battery provides up to 15 hours of backup power.



Specifications

General

  • Supported devices: up to 100

  • Security groups: up to 9

  • Users: up to 50

  • Automation scenarios: up to 5

  • MotionCam support: no

  • Ajax DVRs: up to 14

  • Ajax cameras: up to 224 (via DVRs) or up to 200 standalone

  • Third-party IP cameras: up to 10 (RTSP via SDK) or up to 224 (ONVIF via DVRs)

Communication

  • Protocol: Jeweller (encrypted two-way radio communication, frequency hopping)

  • Range: up to 2000 m (no obstacles)

  • Frequency bands: 866.0–869.2 MHz / 905.0–926.5 MHz

  • ERP power: up to 20 mW (auto-adjusted)

  • Modulation: GFSK

  • Device polling interval: 12–300 s (configurable)

Communication channels

  • Ethernet: 1 × RJ45 (8P8C), up to 100 Mbps

  • SIM: 1 × micro-SIM

  • Cellular networks: GSM 850/900/1800/1900 MHz (2G)

  • Automatic channel switching: yes

  • Channel priority: Ethernet → mobile network

Notifications

  • Types: push, SMS

  • Events: alarms, faults, arming mode changes, system, non-security events

  • Configurable per user

Monitoring

  • Supported protocols: SIA (DC-09), SurGard (Contact ID), ADEMCO 685, others

Power supply

  • Main: 110–240 V~, 50/60 Hz, up to 10 W

  • Backup: Li-ion 3 Ah, up to 15 h (without Ethernet)

  • Alternative: 6–24 V DC (with separate PSU)

Enclosure

  • Dimensions: 163 × 163 × 36 mm

  • Weight: 360 g

  • Temperature: -10°C…+40°C

  • Humidity: up to 75%

  • IP rating: IP20

  • Colours: black, white

Package contents

  • Hub (2G) Jeweller

  • SmartBracket mounting panel

  • Power cable

  • Ethernet cable

  • Installation kit

  • User manual
