Ajax LightSwitch LightCore Jeweller

Sale price 115,47 EUR
Type: 1-gang (1 līnija)
Installation: Yes

LightCore is the core of Ajax LightSwitch smart wall switches. The compact module (only 25 mm depth) does not require a neutral wire and is designed for 200,000 switching cycles. Uses encrypted Jeweller communication with up to 1100 m range.

Models:

  • LightCore 1-gang — single line control

  • LightCore 2-gang — dual line control

  • LightCore 2-way — for two-way switches

Specifications:

  • Classification: Wireless relay for lighting control

  • Installation: wall mount, flush box, horizontal form

  • Power supply: 110–240 V~

  • Load: 5–600 W

  • Power consumption: up to 0.2 W

  • Service life: up to 200,000 switching cycles

  • Protections: overload (>2.6 A), overheat (>+60 °C), overvoltage

  • Communication: Jeweller protocol, range up to 1100 m

  • Frequencies: 866–869 MHz / 905–926 MHz (depending on region)

  • Dimensions: 76.3 × 72.3 × 29.2 mm

  • Weight: 48 g
