Ajax Transmitter Jeweller

Sale price 97,58 EUR
Installation: Yes

Wireless integration module for third-party wired detectors and devices with Ajax security system. Provides full compatibility, encrypted two-way communication, and anti-sabotage protection. Can power connected devices.



Specifications

  • Classification: integration module

  • Installation: indoors/outdoors (sealed box or detector housing)

  • Compatibility: all Ajax hubs & range extenders

  • Alarm input: 1 (NC/NO)

  • Tamper input: 1 (NC/NO)

  • Supported device types: pulse, bistable

  • Power output for devices: 3.3 V⎓

  • Power supply: 3 × CR123A batteries (up to 5 years)

  • Communication range: up to 1,600 m (open space)

  • Radio protocol: Jeweller (868.7–869.2 MHz, ERP ≤ 20 mW)

  • Sensors: temperature sensor, accelerometer

  • Operating temperature: –25°С to +50°С

  • Humidity: up to 75%

  • Dimensions: 100 × 39 × 22 mm

  • Weight: 74 g

Complete set

  • Transmitter

  • 3 × CR123A batteries (pre-installed)

  • Installation kit

  • Quick start guide
